Cedar

Heritage Diagonal Lattice (Contractor)

Name: Heritage Diagonal Lattice (Contractor)
Brand: NorthStar Building Products
SKU: NS-215
Price: 94.99 CAD
Availability: InStock

Value grade: 1×4 boards on a 2×3 OT3 frame.

Availability

● In stock, pickup in Bolton

Price

$94.99 per panel

plus 13% HST at checkout

SKU

NS-215

Pickup at NorthStar Building Products, 240 Ellwood Drive West, Bolton, ON L7E 4W6: in stock, ready next business day (Monday to Friday, 9:00 to 5:00). Come and see one at the yard first if you like.

5.0 on Google from 8 reviews by fence panel customers, checked 28 September 2026

True size 69″ × 96″

“6 ft × 8 ft” is the nominal trade size. Measure your run against the true dimensions before ordering.

Need a different width or height, or a matching gate? Built to order and quoted by hand. Ask for a custom quote.

Pay online and pick up at our Bolton yard. We confirm a time before you drive out.

Deliver to you? Check your postal code

Complete your fence

Posts for this run.

1 panel in one straight run hangs on 2 posts at 96 in. on centre: one at each end and one between every pair.

Post size

4×4 posts$18.79 each, standard runs6×6 posts$48.99 each, heavier, gates and corners

2 × Pressure-Treated 4×4 Fence Post, 10 ft: $37.58 plus HST

Posts are pickup-only. If you want the panels delivered, pick posts up separately or call 647-569-2163 for a lumber delivery quote.

Corners and gates change the count. Price the whole run in the fence calculator.

About this panel

Why we built it this way.

Identical diagonal lattice look at a contractor price point: 1×4 boards on a 2×3 OT3 frame.

4 ft and 5 ft heights and matching gates available; custom sizes on request.

Specifications

Item: NS-215
Size: 6 ft × 8 ft (true 69″ × 96″)
Boards: 1×4 Western Red Cedar
Frame: 2×3 OT3 rails
Top: Hand-set diagonal lattice
Options: 4 ft & 5 ft heights · matching gates · custom sizes

Questions about this panel

Before you order.

Do I need to stain this panel?

Not for durability. Cedar weathers to silver-grey on its own without losing strength. If you want to hold the amber tone, apply a penetrating oil stain after the first 60 days and renew it every two to three years.

How does it install?

Set posts at 96 in. on centre, dig to frost depth (48 in. across most of southern Ontario), and hang the panel between them with hot-dipped galvanised or stainless fasteners. Two people hang a 100 ft run in an afternoon once the posts have cured. Installation guide.

When can I pick it up?

In-stock panels are ready for pickup the next business day at 240 Ellwood Drive West, Bolton, Ontario L7E 4W6, Monday to Friday, 9:00 to 5:00. Order and pay online, and we confirm your pickup time before you drive out.

Do you deliver?

Within about 100 km of Bolton, $200 per 40 panels plus HST, and we call to book a window. Check your postal code on this page before you order; it runs the same rules as the checkout. Pickup at the yard is always free.

What makes the Contractor grade cheaper?

Board and frame size. It carries 1×4 boards on a 2×3 frame where the premium Heritage Diagonal Lattice carries 1×6 boards on a 2×4 frame. The lattice, the look and the 96 in. layout are the same. Heritage Diagonal Lattice, premium grade.
